METTLER TOLEDO 2888 Deckmate Floor Scales Installation and Service Manual
(10/96)
8-4
Ref.
No. Part Number Description Qty.
1 ------------ Same as Standard Platform
2 *TC202772
*TC202782
Portable Frame, Mild Steel
Portable Frame, Stainless Steel
1
3 TN202939 Swivel Caster 4
4 TN202579 Straight - Line Action Clamp 4
5 TA202778-1
TA202778-2
TA202788-1
TA202788-2
TA202779-1
TA202779-2
TA202789-1
TA202789-2
Ramp x 12" Lg. (Optional) Mild Steel Tread Plate
Ramp x 12” Lg. (Optional) Mild Steel Smooth Plate
Ramp x 12" Lg. (Optional) Stainless Steel Tread Plate
Ramp x 12" Lg. (Optional) Stainless Steel Smooth Plate
Ramp x 18" Lg. (Optional) Mild Steel Tread Plate
Ramp x 18" Lg. (Optional) Mild Steel Smooth Plate
Ramp x 18" Lg. (Optional) Stainless Steel Tread Plate
Ramp x 18" Lg. (Optional) Stainless Steel Smooth Plate
Var.
6 TA202918-1 Ramp Mounting KIT (per Ramp) 1
7 TN201817 Bubble Level 1
8 TB202616
TB202618
Instrument Column, Mild Steel
Instrument Column, Stainless Steel
1
9 -------------
MZ0901010076
MZ0901030060
MZ0901030076
MZ0901020016
Column Mounting Hardware:
3/8-16 Hex. Hd. Screw S. S. x 1.25" Lg.
3/8 Flat Washer, S. S.
3/8 Lock Washer, S. S.
3/8 -16 Hex. Nut, S. S.
4
8
4
4
10 --------------
MZ0901010250
MZ0901030069
Battery Pack Mounting Hardware
1/4 - 20 Hex. Hd. Screw S. S. x .38" Lg.
1/4 Lock Washer, S. S.
4
4
11 ------------- Instrument Bracket
12 TN202610 Black Thermoplastic Knob 1
*TN800569 Safety Label is required to be attached to Portable Frame
