Evaluation
The exactness of the battery gauge
depends for example on the temper-
ature, age and strain on the battery
is therefore subject to certain restric-
tions.
The kilometric performance (range)
of the wheelchair should be tested at
least once.
PRE-OPERATION CHECKS
Battery voltage
The battery indicator displays the
battery voltage after the system test
performed by the electronic system
after the operating module has been
switched on (1).
Less LED segments of the battery in-
dicator are lit as the battery voltage
reduces.
Battery display
The battery indicator displays the ex-
isting battery voltage as follows:
The colours mean:
green = batteries charged.
☞ The charging status corre-
sponds to the number of
green lit LEDs.
yellow = recharging recommend-
able.
red = batteries discharged, re-
charge without delay.
☞ Note:
An accurate battery indication is
only given during travel on a level
surface.
Uphill/downhill driving causes an
inaccurate indication.
