OVERVIEW
Operating module VR2 without
light functions
1 Joystick
2 Control panel
3 Battery charging socket
Control panel without light func-
tions
4 Maximum speed / driving profi le
minus
5 Operating module ON/OFF
6 Horn signal
7 Maximum speed / driving profi le
plus
LED-displays
8 Battery indicator
9 Display max. fi nal speed / driving
profi le (only one diode lights up
at a time)
