Operating module VR2 with light
function
1 Joystick
2 Control panel
3 Battery charging socket
Control panel with light func-
tions
4 Left indicator ON/OFF
5 Maximum speed / driving profi le
minus
6 Warning lights on/off
7 Operating module ON/OFF
8 Horn signal
9 Lighting ON/OFF
10 Maximum speed / driving profi le
plus
11 Right indicator ON/OFF
LED-displays
12 Display left indicator
13 Display warning lights
14 Battery indicator
15 Display lighting
16 Display max. fi nal speed / driving
profi le (only one diode lights up
at a time)
17 Display right indicator
Operating module VR2 with light-
adjustment function
18 Adjustment functions
19 Display of the activated adjust-
ment function
