Configuration
System Sensor Temporal
System Sensor March Time
System Sensor California
System Sensor 120 PPM, 50% Duty Cycle
Secutron/Gentex Continuous
Secutron/Gentex Temporal
Secutron/Gentex March Time
Secutron/Gentex California
Secutron/Gentex 120 PPM, 50% Duty Cycle
Wheelock Continuous
Wheelock Temporal
Wheelock March Time
Wheelock California
Wheelock 120 PPM, 50% Duty Cycle
Table 18 Independent Mode DIP Switch Settings - NAC1 and NAC2 configured as
Signals (Continued)
NAC3 NAC4 and NAC5 NAC1 and NAC2 CONFIGURE SWITCHES AS SHOWN
Strobe Manufacturer
(SW5 1-3)
Signal Rate
(SW4 4-6)
SW3 SW4 SW5
