MGE UPS Systems 2200RT - Installing the UPS in a Tower Configuration

Page 12 - 3400753300/AE
Install the two supports for the upright position using provided hardware in the package.
(see item 32 on page 10).
Pull out the MGE Logo and Model plates, then rotate them as shown.
2. Installation
2.3 Installation in tower position
