2. Installation
2.6 Installation of the communications-card option
1 - Remove the slot cover 4 secured by two
screws.
2 - Insert the card in the slot.
3 - Secure the card with the two screws.
Restricted-access slot for
the communications card
4
Pb
Hertz 50/60 Hz
W/VA 1000W/1440VA
Ausg
Hertz 50/60 Hz
Amps 12A MAX
Netz
Util
Load
Mains
Reseau
Volt 120V~1O
Volt 120V~1O
36Vdc, 9Ah
U.S. PAT. NO. 6,094,363
Programmable
2
1
Vac OUT
I max 12A
U.P.S.
34Z5
R
Vac IN
SITE WIRING
FAULT
Data line protection
T20A/125V~
RS232
344-50254-00
INOUT
It is not necessary to shut down the UPS to install the communications card.
This operation must be carried out by qualified personnel.
