Page 20 - 3400723200/AC
3. Operation
3.4 Personalization (optional)
Function
Default setting
Enabled
Enabled
Enabled
Disabled
Enabled
Personalization parameters can be set and modified using the UPS Driver software installed on a computer that is connect-
ed to the UPS (see section 2.4 Connection to the RS232 or USB communications port).
Check that the RS232 21 communications cable is connected.
UPS Driver installation:
1 - Insert the Solution-Pac CD-ROM containing the UPS Driver software in the drive of a PC running Windows.
2 - Open the Windows File manager or Explorer and select the CD-ROM drive.
3 - Double-click "\Emb\Evolutio\Config\upsdriv.exe".
Once UPS Driver has been installed, UPS parameters can be modified in a window containing a number of tabs, each pre-
senting a set of parameters :
Battery tab
Configurable function
Interval between automatic battery tests
Low-battery warning threshold
Protection against deep discharges
Default setting
Once a week
20% of the remaining battery back-
up time
Enabled
Options
Every day
Once a month
No test
10 to 40% of the remaining battery
backup time
Disabled
Options
Disabled
Disabled
Disabled
Enabled
Disabled
ON / OFF conditions tab
Configurable function
Automatic restart
Cold start
Forced reboot
Energy saving
UPS ON / OFF via software
