dsPIC33CK Low-Voltage Motor Control Board User’s Guide
DS50002927A-page 30  2020 Microchip Technology Inc.
FIGURE 3-1: HARDWARE SECTIONS
TABLE 3-1: HARDWARE SECTIONS
1
11
9
8
10
4
4
1
8
4
4
3
6
7
2
5
Section No. Hardware Sections
1 dsPIC33CK256MP508 and Auxiliary Circuits
2 Power Supply
3 Three-Phase Inverter Bridge
4 Current Sensing Circuits
5 Voltage Sensing Circuit
6 Hall Sensor/Quadrature Encoder Interface
7 External Temperature Sensor Interface
8 User Interface
9 Debug Serial UART Interface
10 mikroBUS™ Sockets
11 Programmer/Debugger Interface
