11.3.2 Pinouts for Interfaces
The programming connector pin functions are different for various devices and interfaces. Refer to the following
pinout tables for debug and data stream interfaces.
Note:  Refer to the data sheet for the device you are using as well as the application notes for the specific interface
for additional information and diagrams.
Table 11-5. Pinouts for Debug Interfaces
MPLAB PICkit 4 DEBUG
Connector
Pin
#
Pin
Name
ICSP
(MCHP)
MIPS
EJTAG
CORTEX
®
SWD
AVR
®
JTAG
AVR
ISP(&DW)
UPDI PDI AW DW(IRE) TPI
1 TVPP MCLR MCLR MCLR
2 TVDD VDD VIO_REF VTG VTG VTG VTG VTG VTG VTG VTG
3 GND GND GND GND GND GND GND GND GND GND GND
4 PGD DAT TDO SWO TDO MISO DAT DAT DATA DAT
5 PGC CLK TCK SWCLK TCK SCK CLK
6 TAUX AUX RESET RESET CLK dW RST
7 TTDI TDI TDI MOSI
8 TTMS TMS SWDIO TMS
Table 11-6. Pinouts for Data Stream Interfaces
MPLAB
®
PICkit
4 DATA STREAM
Pin # DMCI / DGI U(S)ART / CDC DGI SPI
1
2 VTG
3 GND
4 MISO
5 SCK
6 (SCK)
7 TX MOSI
8 RX SS
The following figure shows the debugger adapter board (AC102015) pinouts.
Hardware Specification
© 2020 Microchip Technology Inc.
User Guide
DS50002751D-page 60
