© Microhard Systems Inc. 127
4.0 Configuration
Protocol
Select the type of transport protocol used. For example Telnet uses TCP,
SNMP uses UDP, etc.
Values (selection)
External Port
Port number of incoming request (from 4G/WAN-side).
Values (Port #)
2000
TCP / UDP / Both
Name
This is simply a field where a convenient reference or description is added
to the rule. Each Forward must have a unique rule name and can use up to
10 characters.
Values (10 chars)
Forward
Internal Server IP
Enter the IP address of the intended internal (i.e. on LAN side of VIP4G)
server. This is the IP address of the device you are forwarding traffic to.
Values (IP Address)
192.168.2.1
Internal Port
Target port number of internal server on the LAN IP entered above.
Values (Port #)
3000
Source
Select the source for the DMZ traffic, either 4G or from WAN.
Values (selection)
4G / WAN
Exception Port
Enter a exception port number that will NOT be forwarded to the DMZ
server IP. Usually a configuration or remote management port that is
excluded to retain external control of the VIP4G.
Values (Port #)
443
DMZ Server IP
Enter the IP address of the device on the LAN side of the VIP4G where all
the traffic will be forwarded to.
Values (IP Address)
192.168.100.100
DMZ Source
Select the source for the DMZ traffic, either 4G or from WAN.
Values (selection)
4G / WAN
If the firewall is set to block
incoming traffic on the WAN
and/or 4G interfaces,
additional rules or IP/MAC
lists must be configured to
allow desired traffic access.
