802.1x only
IEEE 802.1x is an authentication protocol and every user must use a valid account to
login before accessing the wireless LAN. The authentication is processed by a
RADIUS server. This mode only authenticates user by IEEE 802.1x, but it does not
encrypt the data during communication.
Parameter Description
RADIUS Server IP
address
The IP address of external RADIUS server.
RADIUS Server Port The service port of the external RADIUS server.
RADIUS Server
Password
The password used by external RADIUS server.
Click <Apply> at the bottom of the screen to save the above configurations.
802.1x WEP Static key
IEEE 802.1x is an authentication protocol and every user must use a valid account to
login before accessing the wireless LAN. The authentication is processed by a
RADIUS server. This mode also uses WEP to encrypt the data during communication.
42
