Technical Specification
8.1 Electrical Specification
Parameter
Units
Min
Nominal
Max
Comment
Supply Voltage
Vdc 18 24 32 Inc. ripple
Supply Ripple Vpk-pk 1.0 1.0 1.0
Detector Power Consumption no Heaters W 3.0 3.5 4.0 In Alarm
Detector Power Consumption with heaters W 11 11.5 12 In Alarm
Detector shutdown voltage (low supply) Vdc <18
8.2 Mechanical Specification
Parameter
Units
Value
Comment
Enclosure
Overall Dimensions
mm
100 Diameter x 200 Length
Shipping Weight
Kg
2.5
6
Material
HE30 Aluminium
316SS
Coating
Colour
Red Epoxy Coated Finish
Cable Entries
mm/inches
M25, ¾ NPT
Other variants
on request
Terminal Wire Size
mm
2
2.5
Ingress Protection
IP66 (NEMA 4X)
Mounting Bracket
See figure 1 Mounting Bracket Page 9
Support Fixings
mm
2 x M8
Vertical Adjustment
Degrees
0 to 45
Horizontal Adjustment
Degrees
0
Provided by
support
Axial (horizontal)
Rotation
Degrees
+/- 45
