Appendix D - FM Approval Performance Report
Alarm Response to various stimuli
Stimuli
Low Alarm
Distance
Standard Alarm
Distance
High Alarm
Distance
N-heptane 0.1m
2
pan fire
15 metres
30 metres
60 metres
Ethanol 0.1m
2
pan fire
15 metres
30 metres
42 metres
JP4 0.1m
2
pan fire
No test
30 metres
60 metres
Methane 0.6m plume fire
15 metres
30 metres
50 metres
100W incandescent Lamp steady state
No Alarm 0.9m
No Alarm 1.8m
No Alarm 1.8m
100W incandescent Lamp modulated
No Alarm 0.9m
No Alarm 1.8m
No Alarm 1.8m
Two 40W Fluorescent lamps steady state
No Alarm 0.9m
No Alarm 1.8m
No Alarm 1.8m
Two 40W Fluorescent lamps modulated
No Alarm 0.9m
No Alarm 1.8m
No Alarm 1.8m
500W Quartz Halogen lamp steady state
No Alarm 0.9m
No Alarm 1.8m
No Alarm 1.8m
500W Quartz Halogen lamp modulated
No Alarm 0.9m
No Alarm 1.8m
No Alarm 1.8m
190 Amp Electric arc welding
No Alarm 6.0m
No Alarm 8.0m
No Alarm 10m
3000W electric space heater steady state
No Alarm 1.8m
No Alarm 1.8m
No Alarm 1.8m
3000W electric space heater modulated
No Alarm 1.8m
No Alarm 1.8m
No Alarm 1.8m
1500W electric heater steady state
No Alarm 1.8m
No Alarm 1.8m
No Alarm 1.8m
1500W electric heater modulated
No Alarm 1.8m
No Alarm 1.8m
No Alarm 1.8m
Reflected Sunlight
No Alarm
No Alarm
No Alarm 1.8m
Reflected modulated Sunlight
No Alarm
No Alarm
No Alarm 1.8m
Low Sensitivity response to N-heptane 0.1m
2
pan fire in the presents of False Alarm Stimuli
False Alarm Stimuli
Distance to false Alarm
Distance to Fire
100W incandescent Lamp steady state
0.9m
15 metres Alarm
100W incandescent Lamp modulated
0.9m
15 metres Alarm
Two 40W Fluorescent lamps steady state
0.9m
15 metres Alarm
Two 40W Fluorescent lamps modulated
0.9m
15 metres Alarm
500W Quartz Halogen lamp steady state 0.9m 15 metres Alarm
500W Quartz Halogen lamp modulated
0.9m
15 metres Alarm
190 Amp Electric arc wielding
6.0m
15 metres Alarm
3000W electric space heater steady state
1.8m
15 metres Alarm
3000W electric space heater modulated
1.8m
15 metres Alarm
1500W electric heater steady state
1.8m
15 metres Alarm
1500W electric heater modulated
1.8m
15 metres Alarm
Reflected Sunlight
N/A
15 metres Alarm
Reflected modulated Sunlight
N/A
15 metres Alarm
