Micropack FDS303 - Page 34

34
FDS303 Safety and Technical Manual
Rev: 1.7 ECN: 4535 Ref: 3303.0001
FDS303 Flame Detector
This document is strictly private and confidential, reproduction without Micropack approval is prohibited. © Micropack Engineering Ltd, 2018
Standard Sensitivity response to N-heptane 0.1m
2
pan fire in the presents of False Alarm
Stimuli
High Sensitivity response to N-heptane 0.1m
2
pan fire in the presents of False Alarm Stimuli
False Alarm Stimuli
Distance to false Alarm
Distance to Fire
100W incandescent Lamp steady state
1.8m
60 metres Alarm
100W incandescent Lamp modulated
1.8m
60 metres Alarm
Two 40W Fluorescent lamps steady state
1.8m
60 metres Alarm
Two 40W Fluorescent lamps modulated
1.8m
60 metres Alarm
500W Quartz Halogen lamp steady state
1.8m
60 metres Alarm
500W Quartz Halogen lamp modulated
1.8m
60 metres Alarm
190 Amp Electric arc welding 8.0m 60 metres Alarm
3000W electric space heater steady state
1.8m
60 metres Alarm
3000W electric space heater modulated
1.8m
60 metres Alarm
1500W electric heater steady state 1.8m 60 metres Alarm
1500W electric heater modulated
1.8m
60 metres Alarm
Reflected Sunlight
N/A
60 metres Alarm
Reflected modulated Sunlight
N/A
60 metres Alarm
False Alarm Stimuli
Distance to false Alarm
Distance to Fire
100W incandescent Lamp steady state
1.8m
30 metres Alarm
100W incandescent Lamp modulated
1.8m
30 metres Alarm
Two 40W Fluorescent lamps steady state
1.8m
30 metres Alarm
Two 40W Fluorescent lamps modulated
1.8m
30 metres Alarm
500W Quartz Halogen lamp steady state
1.8m
30 metres Alarm
500W Quartz Halogen lamp modulated
1.8m
30 metres Alarm
190 Amp Electric arc welding
8.0m
30 metres Alarm
3000W electric space heater steady state
1.8m
30 metres Alarm
3000W electric space heater modulated
1.8m
30 metres Alarm
1500W electric heater steady state
1.8m
30 metres Alarm
1500W electric heater modulated
1.8m
30 metres Alarm
Reflected Sunlight
N/A
30 metres Alarm
Reflected modulated Sunlight
N/A
30 metres Alarm
