1. Technical parameters
Dimensions 126x99x43 mm
Weight 270g
Supply voltage 12VDC typ. (9 - 16VDC)
Power consumption 150mA
Operation temperature -20°C / +70°C
Humidity 95% max.
Ethernet 10/100 Base-T
Power connector 5.5/2.1mm connector
Telemetry module connector Terminal block, RS-485 2-wire standard
Thermometer connector Terminal block, DS18B20/DS18S20 standard
Serial ports connector Mini DIN 6-pin, 2 ports, RS-232 standard
Radio connector Mini DIN 6-pin
PC connector USB-B (printer cable type)
4
