Chapter 2 FrontRunner™
2-2 Visionscape FrontRunner™ User’s Manual v4.1.3, April 2012
equally applicable to Visionscape
®
GigE Camera products and Smart
Camera vision systems. It is the GUI you should use to develop and train
vision applications for the VS-1 Smart Camera.
Note: Visionscape
®
V4.1 does not support AppFactory™.
When Visionscape
®
is installed, a Visionscape
®
program folder is created
on your Start Menu. A shortcut for starting FrontRunner™ is located
there. Start FrontRunner™ using this icon. Alternatively, select Start >
Visionscape > Visionscape FrontRunner.
Visionscape
®
V4.1 Firmware
Note: If you open a Visionscape
®
V4.0 Job using Visionscape
®
V4.1, the
Job automatically becomes a V4.1 Job, even if no changes are made to
the Job.
You can monitor, but not program, a V4.0 Job on a VS-1 Smart Camera
with FrontRunner™. Also, you can upload a V4.0 Job and save it to your
PC, at which time it becomes a V4.1 Job.
Basic Concepts
Before you do anything with your VS-1 Smart Camera, make sure it is
mounted properly and wired correctly. You will find mounting and wiring
information in Chapter 2 of the VS-1 Smart Camera Guide.
Device Toolbar and Device Buttons
When you start FrontRunner for the very first time, if you have not
installed any Visionscape
®
GigE Cameras or created any Software
Systems, you will see the following:
• A Device Toolbar that contains no devices (Figure 2–1)
• The dialog box in Figure 2–2
