Microsemi Adaptec ASR-8405E - About the Microsemi Adaptec RAID 8805 E

3.7 About the Microsemi Adaptec RAID 8805E
The Microsemi Adaptec RAID 8805E is a SAS RAID controller with these features:
2 internal mini-SAS HD connectors
HDA mode connector
Mounting bracket
PCIe x8 connector
CNO
C N
1
Low-prole MD2Form Factor
PCIe 3.0Bus compatibility
x8PCIe bus width
12 Gb/s per portData transfer rate
8Phys (Unied Serial Ports)
1024 MB DDR3Standard cache
2 mini-SAS HD x4 (SFF-8643)Connectors, internal
8 direct-attachedMaximum number of disk drives
IBPI and SGPIO (Serial General Purpose Input/Output)Enclosure Support
YesOnboard speaker
NoZero Maintenance Cache Protection Module
9
Microsemi Proprietary and Condential. Installation and User's Guide Revision 5
About Your RAID Controller
