F Technical Specications
F.1 Environmental Specications
Note: Microsemi Adaptec RAID controllers require adequate airow to operate reliably.
The recommended airow is 200 LFM (linear feet per minute), minimum. Forced airow
is required.
0 °C to 55 °CAmbient temperature with forced airow
0 °C to 55 °CAmbient temperature with Flash Backup Unit
10% to 90%, non-condensingRelative humidity
Up to 3,000 metersAltitude
Note: Ambient temperature is measured 1 inch from the RAID controller processor.
F.2 DC Power Requirements
RequirementsDescriptionBus Type
50 mV peak-to-peak (max.)Ripple and noisePCIe
3.3 V ± 9%, 12 V ± 8%DC voltagePCIe
F.3 Current Requirements
Typical CurrentController Model
0.1 A at 3.3 VDC; 1.2 A at 12.0 VDCMicrosemi Adaptec RAID 8405/8405E
0.1 A at 3.3 VDC; 1.2 A at 12.0 VDCMicrosemi Adaptec RAID 8805/8805E
0.1 A at 3.3 VDC; 1.2 A at 12.0 VDCMicrosemi Adaptec RAID 8885/8885Q
1.0 A at 3.3 VDC; 1.1 A at 12.0 VDCMicrosemi Adaptec RAID 81605Z/81605ZQ
F.4 Supercapacitor Ratings
Microsemi Adaptec Flash Backup Module AFM-700Specication
5.4 VMaximum voltage
2.5 VMinimum voltage
0.5 AMaximum rated charge current
0.5 AMaximum rated discharge current
76
