10
Web-Based Management
This section introduces the function of the 4 10/100/1000T plus 1 Mini-GBIC Web
Managed Switch configuration.
About Web-based Management
On the CPU board of the switch there is an embedded HTML web site residing in
flash memory, which offers advanced management features and allow users to
manage the switch from anywhere on the network through a standard browser
such as Microsoft Internet Explorer.
The Web-Based Management supports Internet Explorer 6.0. And, it is applied
with Java Applets for reducing network bandwidth consumption, enhance access
speed and present an easy viewing screen.
System Login
The default value list as below:
IP Address:
192.168.16.1
Subnet Mask:
255.255.255.0
Default Gateway:
192.168.16.254
Password:
root
1. Launch the Internet Explorer.
2. Key in “http://” + “IP Address” of the 4 10/100/1000T plus 1 Mini-GBIC Web
Managed Switch, and then press “
Enter
”.
3. Login screen will appear right after.
To Next Page
