15
Statistics-2 (Detailed)
The following information provides statistics detail information on each port, and
the user can simply click the port to view the statistics information.
Press
to get the
new setting information as below.
Statistics Detail interface
VLAN Setting
A Virtual LAN (VLAN) is a logical network grouping that limits the broadcast
domain, which would allow users to isolate network traffic, and therefore only the
members of the VLAN will receive traffic from the members of the same VLAN.
Basically, creating a VLAN from a switch is logically equivalent to reconnecting a
group of network devices to another Layer 2 switch. However, all the network
devices are still plugged into the same switch physically.
Assign the VLAN ID in number between 1 and 4095.
Group the members of VLAN by ticking the check box.
Click
to bring up the configuration interface as below.
Tick all check boxes by clicking ‘
add all
’ or remove all ticks by clicking ‘
clear
all
’.
