Microsens MS453510M User Manual

13
failure (The default IP is 192.168.16.1).

Fallback Subnet Mask:
Assign the switch IP Subnet Mask.

Fallback Gateway:
Assign the switch Gateway (The default value is
192.168.16.254).

TFTP Server Enabled:
Tick this check box to enable the TFTP server
function.

Management VLAN (1 ~ 4095):
Assign a number of VLAN group between 1
and 4095. It is used for Remote Management Security; in fact, it gives the
port permission to access the switch only when the port’s VLAN group ID is
equal to the Management VLAN ID.

Name:
Assign the name of the switch.

Password:
Web GUI login password. The default password is
root
.

Inactivity Timeout:
Set the timeout period for security in number between
10 and 10000 seconds.

And then, click
Apply
to have the configuration take effect.

Or, click
Refresh
to reset the configuration before applying.
Port Configuration
Specify the negotiation mode, enable flow control, and set maximum frame size
in the range between 1518 and 9600 for each port.

Link:
“Down” means “No Link”. Link speed status includes: 1000FDX,
100FDX, 100HDX, 10FDX, and 10 HDX. The system will automatically
detect link speed.

Mode:
Specify the speed, full-duplex or half-duplex mode of the ports.

Flow control:
Set Flow Control Function as “enable” or “disable” in Full
Duplex mode.

MaxFrame (1522 ~ 9600):
Set the Maximum Frame Size in bytes for frames
received on the port.
