17
Disable the awareness so that ports will not strip the tag from received
frames or insert the tag in transmitted frames.

Frame Type:
Set the outgoing frame.
 Tag: Outgoing frames with VLAN-Tagged.
 All: All type of frames.

Click
Apply
to have the configuration take effect.

Or, click
Refresh
to refresh the configuration to view the newest state.
VLAN Port Setting interface
Port Trunk
Port trunk allows multiple links to be bundled together and act as a single
physical link for increased throughput. It provides load balancing, and
redundancy of links in a switched inter-network. Actually, the link does not have
an inherent total bandwidth equal to the sum of its component physical links.
Traffic in a trunk is distributed across an individual link within the trunk in a
deterministic method that called a hash algorithm. Traffic pattern on the network
