MICROSENS 8 Port Gigabit Ethernet Switch User’s Manual
130
3-18. Diagnostics
Three functions, including Diagnostics, Loopback Test and Ping Test are contained in this
function folder for device self-diagnostics. Each of them will be described in detail orderly in the
following sections.
Function name:
Diagnostics
Function description:
Diagnostics function provides a set of basic system diagnosis. It let users know that whether
the system is health or needs to be fixed. The basic system check includes EEPROM test,
UART test, DRAM test and Flash test.
Fig. 3-68
Diagnostics
Loo
