调高器说明书
3. The actual height of capacitance detection ring is not consistent with its display height
value.
Since "one-keystroke height calibrat
ion" is so simple and it only needs to press one key,
user may calibrate the height controller at any time.
6.2 Commissioning procedure of one-key stroke heig ht calibration
Check and make sure the bottom of capacitance det ection ring is parallel to the work
piece.
Power on the height controller of cutting torch.
Set the detector mode to capacitance detector mode (for the met hod, see 7.3).
In manual mode, adjust the cutting nozzle to approach work piece t o an appropriate
position.
Press and hold t he "down arrow" key on the height control panel for about two
seconds, t
he "one-keyst roke height calibration” process will start a utomatically as
follo
ws:
1. Move up t o somewhere about 30mm high in five steps;
2. And t hen move down to about 10mm away from t he work piece and stop;
3. All the calibration is completed.
By this step, the initial commissioning is finished.
For details about how t o perfo rm height control operation, see 5. 2 and 5.3.
7 Controller Panel
There are LCD display and keypads on the height controller panel.
Through the panel operations, user can modify relevant parameters and
32
