it hits the lower limit switch ( see the input port XXW 8),
the
cutting
torch will stop
descending(M17). Then, the cutt ing torch will ascend (M14) until the positioning delay
of
cutting torch is up (M15);
*11 Remote Height Controller（No）
In order to let user stay away from hazardous cutting site when cont rolling the cutting
operation, and make the use in an easier and, simpler way, a dedicated remote controller is
provided for user, as shown in Fig. X-1.
The remote height controller uses computer-based design and support communicat ion the
master height controller via RS232 port. The adjustment of the height and the sensitivity
adopts simple knob design, which endues it the operation conveniences of analog circuit
and t he accuracy and reliability of digital circuit.
11.1 Function Introduction
44
