调高器说明书
5 Operating Guide
The height controller provides three modes a fter powered on: manual,
automatic and parameter edit
ing modes.
5.1 Parameter Setting
In manual or automatic mode, press the key “Enter” and hold it for some time, the
height controller will enter parameter editing mode. Click the key “Enter” in the
editing
mode, t he height controller will return to manual or automatic mode, which
depends on the mode before entering parameter editing mode.
In editing mode, press the Function key to switch the parameters to be edited
circularly
. The switching sequence is: H (upper limit value) → L (lower limit value) →
A (set value of height) → E (dead-zone value) → d (speed regulating zone value) → C
(detector mode selection) → b (non-board reduction parameters) → H (upper limit
value). ( See 7.3)
If the up arrow is pressed once, the selected parameter value will increase by 1 (for the
selective range of parameter values, see 7.1) .
If the down arrow is pressed
once, the selected parameter value will decrease by 1 (for
the selective range of parameter values, see 7.1)
.
5.2 Manual Operation
Manual/automatic signals: at high level, the contro ller is in manual mode.
Manual ascending signal: at high level, invalid; at low level, the cutting torch moves up.
Manual descending signa l: at high level, invalid; at low level, t he cutt ing t orch moves
down.
If the key "↑" on the operation panel is pressed, t he cut ting head will move up.
If the key "↓" on the operation panel is pressed, t he cutt ing torch will move down.
Modify the corresponding set value of height when the height controller is ascending or
descending in manual mode.
30
