Microtek LS-3800 User Manual

26 LS-3800 User's Manual
Specifications
Model Name LS-3800
Model Number MLS-600A1
Image Sensor CCD
Light Source LED (Light Emitting Diode)
Scanning Modes Color and grayscale in a single scanning pass
Input: 48-bit color/16-bit grayscale
Output: 24-bit color/8-bit grayscale
Resolution 800 dpi
Scanning Area 24“ x 37” (610 mm x 940 mm)
Scanning Speed 30 sec @ 200 dpi, A1 color
Interface Hi-Speed USB (USB 2.0)
Dimensions (L x W x H) 52.4" x 34.3" x 34.7"
(1330 mm x 870 mm x 880 mm)
(Upper cover is not included)
Weight 379 lbs. (172 kg)
Voltage AC 100V to 240V, 50/60 Hz
1.7A Max (Input)
Environment Operating temperature: 50° to 95°F (10° to 35°C)
Relative humidity: 20% to 85%
Warranty Machine: 50,000 scans @ 300 dpi, A1 size
or 1 year for normal use
Upper cover: 10,000 times
Glass (Scan bed): Under the warranty period,
warranty conditions will not cover the damages
caused by natural disaster or inappropriate use.
Important: Please never attempt to open or service the machine by yourself;
or, this will void your warranty.
Specications, software bundles, and accessories are subject to change
without notice. Not responsible for typographic errors.

Microtek LS-3800 Specifications

Scanning

resolution	800 dpi
scanning area	24" x 37" (610 mm x 940 mm)
scanning speed	30 sec @ 200 dpi, A1 color

Power

voltage	AC 100V to 240V
frequency	50/60 Hz
current	1.7A Max

Operating Environment

operating temperature	50° to 95°F (10° to 35°C)
relative humidity	20% to 85%
light source	LED (Light Emitting Diode)

Weight and Dimensions

dimensions	52.4" x 34.3" x 34.7"
weight	379 lbs.
dimensions in mm	1330 mm x 870 mm x 880 mm
