30 ScanMaker i800 Supplement
System Requirements
General Requirements
• CD-ROM drive (for installing software)
• Color display with 24-bit color output capability
• 128MB RAM (256MB or more to use DIGITAL ICE Technology)
PC and compatibles
• Pentium III PC or higher with USB, Hi-Speed USB (USB 2.0), or FireWire (IEEE
1394) port
• Microsoft Windows 98SE, Me, 2000 or XP
Macintosh
• iMac or Mac G3/G4/G5 with built-in USB port or FireWire port
• Mac OS 9.x, OS X 10.2 - 10.3
Specifications
Scanning Modes Color, grayscale, and black-and-white in a single scanning
pass
True 48-bit color (approx. 281 x 10
12
colors)
16-bit grayscale (approx. 65,536 shades of gray)
Scanning Area Reflective: 8.5" x 14" (216 mm x 356 mm)
Transparent: 8" x 12" (203 mm x 305 mm)
Resolution Optical: 9600 dpi x 4800 dpi
Interpolated: 65,535 dpi (PC); 32,767 dpi (Mac)
Dynamic Range 4.0 Dmax
Interface Hi-Speed USB (USB 2.0) and FireWire (IEEE 1394)
Dimensions (L x W x H) 22.6" x 11.7" x 4.6" (576 mm x 297 mm x 118 mm)
Net Weight 14.1 lbs (6.4 kg)
Voltage AC 100V to 240V
1.2A Max; 47-63 Hz (Input)
15V/2.5A (Output)
Environment Operating Temperature: 50° F to 104° F (10° C to 40° C)
Relative Humidity: 20% to 85%
Power supply Manufacturer Model No. Voltage
(AC/DC adapter) FAIRWAY VE50-150A 100V to 240V
Important
Specifications, bundles, and accessories are subject to change without notice.
