Midas M32 Digital Console User Manual

46 M32 DIGITAL CONSOLE User Manual
4. Appendices
4.1 Appendix A: Technical Specications
Processing
Input Processing Channels 32 Input Channels, 8 Aux Channels, 8 FX Return Channels
Output Processing Channels 8 / 16
16 aux buses, 6 matrices, main LRC 100
Internal Eects Engines (True Stereo / Mono) 8 / 16
Internal Show Automation (structured Cues / Snippets) 500 / 100
Internal Total Recall Scenes (incl. Preampliers and Faders) 100
Signal Processing 40-Bit Floating Point
A/D Conversion (8-channel, 96 kHz ready) 24-Bit, 114 dB Dynamic Range A-weighted*
D/A Conversion (stereo, 96 kHz ready) 24-Bit, 120 dB Dynamic Range A-weighted*
I/O Latency (Console Input to Output) 0.8 ms
Network Latency (Stage Box In > Console > Stage Box Out) 1.1 ms
* A-weighted gures are typically ~3 dB better
Connectors
MIDAS PRO Series Microphone Preamplier (XLR) 32
Talkback Microphone Input (XLR) 1
RCA Inputs / Outputs 2/2
XLR Outputs 16
Monitoring Outputs (XLR / ¼” TRS Balanced) 2/2
Aux Inputs/Outputs (¼” TRS Balanced) 6/6
Phones Output (¼” TRS) 2 (Stereo)
Digital AES/EBU Output (XLR) 1
AES50 Ports (KLARK TEKNIK SuperMAC) 2
Expansion Card Interface 32 Channel Audio Input / Output
ULTRANET P-16 Connector (No Power Supplied) 1
MIDI Inputs / Outputs 1/1
USB Type A (Audio and Data Import / Export) 1
USB Type B, rear panel, for remote control 1
Ethernet, RJ45, rear panel, for remote control 1
Mic Input Characteristics
Design MIDAS PRO Series
THD+N (0 dB gain, 0 dBu output) < 0.01% unweighted
THD+N (+40 dB gain, 0 dBu to +20 dBu output) < 0.03% unweighted
Input Impedance (Unbalanced / Balanced) 10 kΩ / 10 kΩ
Non-Clip Maximum Input Level +23 dBu
Phantom Power (Switchable per Input) +48 V
Equivalent Input Noise @ +45dB gain (150 Ω source) -125 dBu 22 Hz-22 kHz unweighted
CMRR @ Unity Gain (Typical) > 70 dB
CMRR @ 40 dB Gain (Typical) > 90 dB

Midas M32 Digital Console Specifications

General

Brand	Midas
Model	M32 Digital Console
Category	Music Mixer
Language	English
