49 M32 DIGITAL CONSOLE User Manual
For Program Changes ‘Value’ 0…127 = program/preset number, that will be sent
upon pressingthe button.
MIDI Toggle
Can be assigned to sending control changes or notes
Parameters are currently ‘Channel’ and ‘Value’
For CC and Note commands ‘Value’ 0…127 = controller number/note number,
and the button toggles the controller value/note-on velocity
Between value/velocity 127 and 0 with every operation.
PLEASE NOTE:
The ASSIGN section also reects/displays reception of the same MIDI commands
that are selected for transmission
The MIDI commands assigned to the ASSIGN controls can be transferred to and
from stage via AES50 using the S16 stage box MIDI I/O.
MIDIRX/TX > Remote
Enables a specic form of bi-directional MIDI communication for remote
controlling a computer DAW application using control elements of the M32
console.REMOTEcan be used in threemodes,MackieControl,HUIand rawMIDI
CC (raw)controllers (see SETUP / remote)
MIDI CC (raw) selected and Remote is enabled+active, thegroup section controls
will transmit/receive the following messages:
HUI selected and Remote is enabled+active, then the group fader section and
buttons will emulate the HUI control surface protocol, i.e. for ProTools.
SELECT/SOLO 1-8 buttons will select or solo the corresponding track in the DAW,
in banks of eighttracks
MIDI RX MIDI Ch Controller Comment
Group 1-8 SELECT 1 Note 64-71 on (127) / o (0), push non-latching
Group 1-8 SOLO 1 CC 32-39 on (127) / o (0), toggle latching
Group 1-8 MUTE 1 CC 40-47 on (127) / o (0), toggle latching
Sends On Fader 1 CC 48 on (127) / o (0), toggle latching
Group DCA 1-8 1 Note 72 on (127) / o (0), push non-latching
BUS 1-8 1 Note 73 on (127) / o (0), push non-latching
BUS 9-16 1 Note 74 on (127) / o (0), push non-latching
MTX 1-6 1 Note 75 on (127) / o (0), push non-latching
GROUP Faders 1 CC0-7 0-127
Sends On Fader = enables touch-writing a fader automation on selected track,
trackautomation mode in DAW must be ‘touch’, (latching)
Use the layer buttons to determine the function assigned to the MUTE 1-8
buttons, the LED displays indicate that function.
• Group DCA 1-8 = allows movement of the bank selection of tracks in a DAW,
(push non-latching)
• BUS 1-8 = allows the setting of DAW tracks to ‘Record Ready’,
(pushnon-latching)
• BUS 9-16 = enables use of MUTE buttons for track mute in
theDAW,(latching)
• MTX 1-6 = enables use of MUTE buttons for transport controls in
theDAW,(latching).
MACKIE CTRL selected and Remote is enabled+active, then the group fader
section and buttons will emulate the Mackie Control Universal protocol
SELECT/SOLO 1-8 buttons will select or solo the corresponding track in the DAW,
in banks of eighttracks
Sends On Fader = enables touch-writing a fader automation on selected track,
track automation mode in DAW must be ‘touch’ or ‘latch’, (latching)
Use the layer buttons to determine the function assigned to the MUTE 1-8
buttons, the LED displays indicate that function.
• Group DCA 1-8 = allows movement of the bank selection of tracks in a DAW,
(push non-latching)
• BUS 1-8 = allows the setting of DAW tracks to ‘Record Ready’,
(push non-latching)
• BUS 9-16 = enables use of the MUTE buttons for track mute in
theDAW,(latching)
• MTX 1-6 = enables use of the MUTE buttons for transport controls in
theDAW, (latching).
