44 Chapter 6: Dual Stereo Input Channel
VeniceF
Operator Manual
Overview of the dual stereo input channel
The VeniceF dual stereo channel (shown right) is equipped with two XLR
inputs, which are used for mic/line level signals up to +32dBu. Two 1/4”
TRS Jack sockets provide inputs for line level signals that require
protection against accidental 48-volt connection. The line inputs accept
signals up to +28dBu and have +20dB of gain available.
Item Section
1 Stereo mic input gain (see “Gain (stereo mic inputs)” on
page 46).
2 FireWire (see “FireWire” on page 46).
3 Stereo line input gain (see “Stereo line inputs” on page 47).
4 EQ (see “EQ” on page 48).
5 Monitors and auxes (see “Monitors” on page 49 and “Auxes”
on page 49).
6 Groups, panning and solo (see “Pan, routing, mute and solo”
on page 50 and “Fader and meter” on page 52).
7 Fader (see “Fader and meter” on page 52).
