53
VeniceF
Operator Manual
Chapter 7: Output Section
This chapter deals with the output section of the VeniceF. It describes the control
surface and the related connectors on the rear panel.
Output section of the control surface
The output section comprises the following main areas:
• Group (see “Groups” on page 57)
• Matrix (see “Matrices” on page 61)
• Stereo return (see “Stereo returns” on page 63)
• Monitor (see “Monitors” on page 64)
• Aux (see “Auxes” on page 65)
• Mono master (see “Master outputs (mono and stereo)” on page 66)
• Stereo master (see “Master outputs (mono and stereo)” on page 66)
• Talkback (see “Signal generator and talkback” on page 68)
• Playback (to masters) (see “Playback and recording” on page 69)
• Local monitor (see “Local monitor and phones” on page 70)
