4 Chapter 1: Introduction
VeniceF
Operator Manual
• Mains power supply — universal power supply unit (PSU) with mains input socket
and on/off switch.
• Lamps — socket(s) for fitting lamps.
• Playback/record I/Os — input/output sockets for playback and recording.
• Warranty — standard Midas 3-year warranty.
Control surface
The surface of the VeniceF can be divided into the following main vertical sections.
Control surfaces of the VeniceF consoles showing the three mains areas
Item Description
1 See Chapter 5 "Mono Input Channel" on page 31
2 See Chapter 6 "Dual Stereo Input Channel" on page 43
3 See Chapter 7 "Output Section" on page 53
