RM-KB-LCD17x8/16KVM User Manual
8
No. Component Description
1 Handle Pull to slide the KVM module out; push to slide the module in
(see item 2 in this table).
2 LCD Display After sliding the KVM module out, flip up the cover to access
the LCD monitor.
3 LCD Controls The LCD On/Off switch is located here, as well as buttons to
control the position and picture settings of the LCD display.
See page 26 for details.
4 Port LEDs An ON LINE LED lights to indicate that the computer
attached to its corresponding port is up and running.
5 Keyboard Standard 105-key keyboard
6 Touchpad Standard mouse touchpad
7 Port Switches Press the UP or DOWN buttons for the Port ID to bring the
KVM focus to the computer attached to the corresponding
port. See Manual Port Switching, page 29.
8 External Mouse
Port
A USB mouse port is provided for users who prefer to use an
external mouse.
9 Power LED Lights to indicate that the unit is receiving power.
10 Rack Mounting
Brackets
The rack mount brackets located at each corner of the unit
secure the chassis to a system rack.
11 Lock LEDs Num Lock, Caps Lock, Scroll Lock LEDs are located here.
12 Reset Switch Located to the right of the Lock LEDs. Press this recessed
switch in with a small object to perform a system reset.
13 USB Port The USB port is available to connect a USB 1.1 peripheral
device (flash drive, CD-ROM drive, etc.) to the switch.
14 Firmware
Upgrade
Section
Firmware Upgrade Port: The Firmware Upgrade Cable
that transfers the firmware upgrade data from the adminis-
trator's computer to the RM-KB-LCD17x8/16KVM plugs
into this RJ-11 connector.
Firmware Upgrade Switch: During normal operation this
switch should be in the NORMAL position. (See The Firm-
ware Upgrade Utility, page 53 for firmware upgrading
details.)
