Specifications
Function RM-KB-LCD17x8 RM-KB-LCD17x16
Computer Connections 8 16
Port Selection OSD, Hotkeys, Pushbuttons
Connectors External Console Port 1 x SPHD-18 (Male)
External Mouse Port 1 x USB Type-A (Female)
KVM Ports 8 x SPHD-15 (Female) 16 x SPHD-15 (Female)
FW Upgrade 1 x RJ-11 (Female)
Power 1 x 3-prong AC Socket
USB 1.1 Hub 1 x USB Type-A (Female)
Switches Reset 1 x Semi-recessed Pushbutton
Power 1 x Rocker Switch
Firmware
Upgrade
1 x Switch
LCD
Adjust
4 x Pushbutton
LCD On/
Off
1 x LED Pushbutton (Orange)
Port
Selection
2 x Pushbutton
LEDs On Line 8 (Orange) 16 (Orange)
Port ID 2 x 7-segment LED Display (Yellow)
Power 1 (Dark Green)
Lock Num 1 (Green)
Caps 1 (Green)
Scroll 1 (Green)
Emulation Keyboard / Mouse PS/2, USB
Video 1280 x 1024 @ 75 Hz; DDC2B
Scan Interval (OSD Select) 1–255 sec.
I/P Rating 100–240 VAC, 50/60 Hz, 1 A
Power Consumption 120V, 27.5W / 230V, 28W
Environment Operating Temp.
32–104º F (0–40
o
C)
Storage Temp.
-4–140ºF (-20–60
o
C)
Humidity 0–80% RH, Noncondensing
Physical
Properties
Housing Metal + Plastic
Weight 32.12 lb. (14.57 kg) 32.47 lb. (14.73 kg)
Dimensions (L x W x H) 22.75 x 19.01 x 1.65 in
(57.80 x 48.30 x 4.42 cm)
22.75 x 19.01 x 1.65 in
(57.80 x 48.30 x 4.42 cm)
