RM-KB-LCD17x8/16KVM User Manual
54
Preparation
To prepare for the firmware upgrade, do the following:
1. Use the Firmware Upgrade Cable (provided with this unit), to connect a
COM port on your computer to the Firmware Upgrade Port of your
switch.
2. Shut down all the computers connected to the KVM ports.
3. From your KVM switch console, login to the OSD as the administrator
(see page 31) and select the F4 ADM function.
4. Scroll down to FIRMWARE UPGRADE. Press [Enter], then press [Y] to
invoke Firmware Upgrade mode (see page 40.).
Note: During Firmware Upgrade mode, the port LEDs will flash on and off.
To Next Page
