RM-KB-LCD17x8/16KVM User Manual
16
Single Level Installation
To set up a single level installation, refer to the installation instructions and
diagrams on the following pages (the numbers in the diagrams correspond to
the numbers of the installation steps).
1. Ground the unit.
2. If you choose to connect an external console to the RM-KB-LCD17x8/
16KVM, use the console cable provided to plug a keyboard, monitor, and
mouse into the Console Port. See Cabling Diagrams, page 18.
Note: 1. Using an external console is optional.
2. The maximum distance between the switch and the external
monitor is 65.62 feet. (20 m).
3. For each of the computers you are installing, use a KVM cable set (as
described in the Cables section on page 5), to connect any available KVM
port to the computer's keyboard, video and mouse ports. See KVM Cable
Installation Diagrams, page 18.
Note: The maximum distance between the switch and a computer is 10 m.
4. Plug the power cord into the AC power socket of the RM-KB-LCD17x8/
16KVM and the other end into a AC power source.
5. Power on the RM-KB-LCD17x8/16KVM (see Powering Off and
Restarting, page 25 for details). After the RM-KB-LCD17x8/16KVM is
powered on, power on the computers.
