Middleby Marshall PS540 (Double) - Split Belt Conveyor

59
ENGLISH
SECTION 6
PARTS LIST
SPLIT BELT CONVEYOR
ITEM QTY. P/N DESCRIPTION
ITEM QTY. P/N DESCRIPTION
1 1 50646 SPLIT CONVEYOR 50/50 80″
EXCLUDES ITEMS 7, 8, 9, 12, 36 & 37
2 1 22450-0226 CONVEYOR BELT, 1/2P
15″ × 146″ 2.86/5 SP
3 1 33900-0037 CONVEYOR CHAIN, SS WIRE1 FT 4 1 51382 KIT, MASTER LINK,
CONTAINS ((1) 33900-0016,
(1) 33900-0017, (1) 33900-0018)
5 1 33900-0016 MASTER LINK - LEFT 1/2P × 32″ 6 1 33900-0017 MASTER LINK - MIDDLE 1/2P × 32″ 7 1 33900-0018 MASTER LINK - RIGHT 1/2P × 32″ 8 4 2001371 NUT, KEPS 10-32, ZP 9 2 50265 CONVEYOR CONTROL PICKUP
KIT(NOT SHOWN)
10 1 49400-0070 ROLLER CHAIN ASSEMBLY, SPB 15″ 11 1 49400-0051 ROLLER CHAIN ASSEMBLY, SPB 26-1/2″ 12 1 22159-0003 SPROCKET, #25-20T-5/8″ 13 1 22159-0004 SPROCKET, #25-30T-1/2″ 14 1 49400-0092 COMPLETE FOLDING CONVEYOR SPB
ASSY INCLUDES ITEMS 15, 15, 16, 19 & 36
15 2 35900-0398 PIVOT PLATE - CONVEYOR FRAME 16 4 21176-0002 LOCKNUT, HEX SS 3/8″-16
17 16 22229-0003 CONVEYOR DRIVE SPROCKET
2.0″ OD W/SCREW
18 1 49400-0093 CONVEYOR FRAME ASSEMBLY - IDLER
INCLUDES ITEMS 17, 19, 20, 21, 22, 23 & 24
19 1 37900-0071 COMPLETE CONVEYOR FRAME
WELDMENT - IDLER
20 2 22034-0003 BUSHING, FLANGE 3/4″ OD, × 5/8″ ID N/D
21 2 35000-1008 SCREW, ADJ - CONVEYOR IDLER 22 2 35900-0020 CONVEYOR SHAFT SUPPORT BRACKET 23 2 37000-0413 IDLER WELDMENT 24 1 35525 IDLER SHAFT ASSEMBLY, SPB
INCLUDES ITEMS 25, 26 & 27
25 2 21415-0001 FLAT WASHER, BRONZE 26 1 35000-1535 REAR CONVEYOR IDLER SHAFT, SPB 27 1 42400-0354 FRONT CONVEYOR IDLER SHAFT
ASSEMBLY, SPB
28 1 49400-0095 CONVEYOR FRAME-DRIVE ASSY, SPB
INCLUDES ITEMS 12, 17, 20, 22, 29, 30, 31, 32, 35 & 36
29 1 22011-0014 SPLIT-SHAFT COLLAR 30 2 35000-1080 NYLON SPACER 3/4″ ID 1-1/4″ OD 31 1 35000-1531 NYLON SPACER 32 1 35524 DRIVE SHAFT ASSEMBLY, SPB
INCLUDES ITEMS 25, 33 & 34
33 1 35900-0022 CONN-REAR CONVEYOR DRIVE SHAFT 34 1 49400-0018 FRONT CONVEYOR DRIVE SHAFTASSY, SPB 35 1 35900-0023 BUSHING, SPROCKET-FRONT DRIVE 36 1 37900-0075 COMPLETE CONVEYOR FRAME-
DRIVE WELDMENT
37 1 35000-1103 STOP, SIDE END CONVEYOR EXT 38 1 35900-0148 STOP, BACK SIDE CONVEYOR EXT 39 2 35900-0255 CRUMB PAN W/SLOTS - CONVEYOR 40 2 35900-0305 CRUMB PAN - CONVEYOR 41 2 47797 MOTOR, GEAR 1/50HP 1350:1
