Middleby Marshall PS540 (Double) - Oven Panels, Window and Legs

51
ENGLISH
SECTION 6
PARTS LIST
OVEN PANELS, WINDOW AND LEGS
ITEM QTY. P/N DESCRIPTION
1 2 49947 UPPER END PLUG ASSEMBLY 2 2 49946 LOWER END PLUG ASSEMBLY 3 8 36452 WING NUT, PLASTIC 1/4-20 4 8 45449 END PLUG MOUNTING PLATE ASSEMBLY 5 16 21296-0005 SCREW, HEX WSHHD12-14 × 3/4″, SS BSD 6 1 49905 CONVEYOR CHAIN COVER 7 2 50637 EYEBROW 8 1 33486 COVER, TOP 304 PANEL 9 4 21256-0008 SCREW, 10-32 × 3/8″ 18-8 SL TRUS S
10 1 37900-0103 WINDOW MOUNTING FRAME WELDMENT 11 1 30285 GLASS DOOR ASSEMBLY 12 1 42400-0087 WINDOW LATCH ASSEMBLY 13 1 54606 COMPLETE BASE WELDMENT 14 4 37900-0024 LEG/TOP PLATE WELDMENT 15 4 37900-0102 LEG 6″ H/TOP PLATE WELDMENT 16 2 22290-0009 CASTER, SWVL W/BRAKE FLAT PLATE 17 2 22290-0010 CASTER SWVL FLAT PLATE 18 A/R 220373 SCREW, HEX HEAD, 3/8″ - 16 × 1″ SST 19 A/R 21422-0001 WASHER, LOCK SPLIT 3/8″ 20 A/R 21416-0001 FLAT WASHER, 3/8″ ZP 21 1 22500-0021 NAME PLATE 22 1 22500-0101 INSTRUCTION LABEL 23 1 22500-0041 LABEL, “CAUTION HOT SURFACE” 24 16 21172-0004 NUT, 3/8″-16 NYLON INSULATED L/N ZC 25 8 21416-0003 FLAT WASHER 1/2″ 18-8 26 8 21426-0004 LOCK WASHER 1/2″ 18-8 27 8 21216-0018 SCREW, HHCS 1/2-13 × 1-1/4″ 18-8 28 4 45205 QUAD CASTER SPACER 29 4 45209 QUAD OUTRIGGER WELDMENT 30 4 45206 QUAD ADJUSTMENT FOOT INSERT
