61
ENGLISH
SECTION 6
PARTS LIST
MACHINERY COMPARTMENT
ITEM QTY. P/N DESCRIPTION
1 1 28021-0047 INTERLOCK SWITCH 10A NO2P
2 1 28021-0061 MOMENTARY SWITCH - 10A NO 2 POLE
3 1 44687 MOTOR 1/2 HP
4 1 49953 MOTOR MOUNTING BRACKET WELDMENT
5 1 50449 MOTOR SUPPORT BRACKET
6 8 1513D8805 SCREW, HEX HD 3/8″-16 × 3/4″ - NP
7 8 21422-0001 LOCK WASHER, SPLIT 3/8″ ZP
8 8 21416-0001 FLAT WASHER SS 3/8″
9 4 A3896 MACHINE SCREW, HEX HD 5/16″-18 × 1″ 18-8
10 4 3023A8807 FLAT WASHER 5/16″ SAE NP
11 4 21126-0004 HEX NUT SS 5/16-18
12 4 A3682 LOCK WASHER 5/16″
13 1 36451 COOLING FAN 230V AC
14 1 31497 FINGER COOLING FAN GUARD
15 1 33812-3 THERMOCOUPLE, TYPE “J” SHIELDED 9.50 × 60″
