Service Manual_2018-V2.0
19
7.Refrigerating piping system and circulating route of cooling air
7.1 Refrigerating piping system
❶Compressor→❷ Anti-condensation tube→❸ Condenser→❹ Dry filter→❺ Capillary tube→❻
Evaporator→❼ Suction tube→❶Compressor
7.2 Special soldering position
