Service Manual_2018-V2.0
32
9.3 Sensor replacement
The sensor is located on the inner side of the upper
hinge cover and sends temperature signal to
microprocessor.
Defrost sensor in refrigerating chamber
The defrost sensor is located on top of the evaporator.
1）Disconnect the connector of defrost sensor
2）Cut off the band which fixes the sensor.
3）Separate the sensor and the evaporator.
Sensor replacement guidelines
Cut off the damaged head of sensor.
Strip off the sensor wiring.
Take out a new sensor to cut the head of sensor.
(Spare parts code：11201007000795) Its technical
specifications apply to all MIDEA refrigerators.
