Service Manual_2018-V2.0
31
9. temperature sensing system
9.1 Position of sensors
9.2 Replacement of sensors
Have 3sensors
① Sensor in freezing chamberSensor in
refrigerating chamber
② Sensor in Variable temperature
chamberAmbient temperature or
humidity sensorIce machine sensor
③ Defrost sensor in refrigerating chamber
④ Defrost sensor freezing chamber
Sensor in refrigerating chamber
Before remove the sensor, the freezer duct assembly
should be removed
1）Remove the air duct assembly from the freezer.
2）Remove the sensor.
Ambient temperature sensor
