Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
3
SPECIFICATIONS
Table 2 — Specifications
Compatibility
Table 3 — Compatibility
SYSTEM SIZE 12K 9K 12K 18K 24K
Indoor Model DLFSHBH12XAJ DLFSHBH09XAK DLFSHBH12XAK DLFSHBH18XAK DLFSHBH24XAK
Electrical
Voltage, Phase,
Cycle
V/Ph/Hz 115-1-60 208/230-1-60 208/230-1-60 208/230-1-60 208/230-1-60
Power Supply
MCA A. 0.31 0.19 0.19 0.5 0.5
Controls
Wireless Remote
Controller (°F/°C
Convertible)
Standard Standard Standard Standard Standard
Wired Remote
Controller (°F/°C
Convertible)
Optional Optional Optional Optional Optional
Operating
Range
Cooling Indoor DB
Min - Max
°F(°C) 62~90 (17~32) 62~90 (17~32) 62~90 (17~32) 62~90 (17~32) 62~90 (17~32)
Heating Indoor DB
Min - Max
°F(°C) 32~86 (0~30) 32~86 (0~30) 32~86 (0~30) 32~86 (0~30) 32~86 (0~30)
Piping
Pipe Connection
Size - Liquid
in (mm) 1/4 (6.35) 1/4 (6.35) 1/4 (6.35) 1/4 (6.35) 3/8 (9.52)
Pipe Connection
Size - Suction
in (mm) 1/2 (12.7) 3/8 (9.52) 1/2 (12.7) 1/2 (12.7) 5/8 (16)
Indoor Coil
Face Area Sq. Ft. 2.05 2.05 2.05 2.67 2.67
No. Rows 22222
Fins per inch 20 20 20 20 20
Circuits 22244
Indoor
Unit Width in (mm) 31.57 (802) 31.57 (802) 31.57 (802) 42.60 (1082) 42.60 (1082)
Unit Height in (mm) 11.61 (295) 11.61 (295) 11.61 (295) 13.27 (337) 13.27 (337)
Unit Depth in (mm) 7.87 (200) 7.87 (200) 7.87 (200) 9.21 (234) 9.21 (234)
Net Weight lbs (kg) 18.96 (8.6) 18.96 (8.6) 18.96 (8.6) 29.54 (13.4) 29.98 (13.6)
Fan Speeds 4 4 4 4 4
Airflow
(lowest to highest)
CFM 176/241/300/341 152/194/291/341 152/194/291/341 382/458/531/761 382/459/601/761
Sound Pressure
(lowest to highest)
dB(A) 29.8/32.3/38.6 32.3/35.5/41.2 32.9/35.6/41 37.9/40.9/46.3 41/45.1/49.8
Air throw Data ft (m) 23 (7) 19.7 (6) 22.3 (6.8) 31.8 (9.7) 34.4 (10.5)
Moisture removal
Pint/h
(L/h)
0.058 (0.028) 0.039 (0.014) 0.061 (0.029) 0.072 (0.034) 0.106 (0.051)
Field Drain Pipe
Size O.D.
in (mm) 0.625 (16) 0.625 (16) 0.625 (16) 0.625 (16) 0.625 (16)
Indoor Unit DLFSHBH12XAJ DLFSHBH09XAK DLFSHBH12XAK DLFSHBH18XAK DLFSHBH24XAK
Outdoor Unit
Single Zone
DLCSRBH12AAJ DLCSRBH09AAK DLCSRBH12AAK DLCSRBH18AAK DLCSRBH24AAK
Outdoor Unit Multi-zone
DLCMRAH18BAK
DLCMRAH27CAK
DLCMRAH36DAK
DLCMRAH48EAK
