Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
50
DISASSEMBLY INSTRUCTIONS (CONT)
Fan Motor and Fan
noitartsullIerudecorP
1) Remove the screws (2) and remove the
fixing board of the fan motor.
2) Remove the bearing sleeve.
Screws
