Service Manual_2023-V2.0
13
3.4 Leveling of the refrigerator
Leveling of the refrigerator
If the refrigerator cannot be placed steadily, adjust the
footing to level it. Turn the feet clockwise to raise the
refrigerator; turn the feet counterclockwise to lower the
refrigerator.
3.5 Adjustment to level the door
Adjustment to level the door（Up and down ）
1) Refrigerator door lower: loosen locking nut
counterclockwise, then rotate the adjusting nut
counterclockwise to adjust the height of door, at last
tighten the locking nut clockwise.
2) Refrigerator door higher: loosen locking nut
counterclockwise firstly, then rotate the adjusting nut
clockwise, at last tighten the locking nut clockwise.
Adjustment to inhomogenous aperture the door (Up and down)
1) Use screwdriver to remove the 5 pcs screws, and
then remove the upper hinge cover.
To Next Page
