Service Manual_2023-V2.0
12
assembly of refrigerator door
1) Put the refrigerator door down gently until the axis of
hinge inserted into the axis hole of door completely, and
then closes the door, to make sure the refrigerator door
fit the cabinet closely.
2) Put the upper hinge on suitable position, then use
cross screwdriver or socket spanner to fix the 2 pcs M5
screws.
3) Put the hinge cover on suitable position, and then use
the screwdriver to fix the 5 pcs screws.
3.3 Installation location
Please select a ventilated place to place the refrigerator,
and reserve space according to the recommended size
in the picture, which is conducive to heat dissipation,
performance improvement and energy consumption
reduction.
