Service Manual_2023-V2.0
11
1) Put the freezer door down gently until the axis of
hinge inserted into the axis hole of door completely.
2) Put the upper hinge on suitable position, then use
cross screwdriver or socket spanner to fix the 2 pcs M5
screws and 1 pc grounding screw by clockwise, and
connect the 6 pcs fast connectors.
3) Push the locked cushion of water connector inwards,
then insert the water pipe into the water connector to the
end, and finally assemble the spacing guard sheet.
Note: the water pipe can’t be connected incorrectly, only
the water pipes in same color can be connected
4) Assemble the protective cover and fix the screws
To Next Page
