Page 7
Set Up
Instructions
SET UP INSTRUCTIONS
Step 1:
Separate dehumidifier & bucket from the nested shipping/storage position. Remove all
packaging materials from the unit.
Step 2:
Rotate dehumidifier 90° and align the arrows on the two labels (one on the bucket
and one on the dehumidifier) and carefully sit the dehumidifier down onto the bucket.
The water level window in the bucket and the user interface buttons on the
dehumidifier should be on the same side when properly stacked. Check to ensure
the arrows on the unit and bucket are aligned as in Fig. 4c for proper operation.
Step 3:
Plug the unit in and press the power button and the unit is ready to run in normal
(bucket) mode.
Nested Shipping &
Storage Position
Fig. 3a
Fig. 3b
Rotate dehumidifi er 90°
Fig. 4a
User Interface
Buttons and
Water Level
Window
Aligned on the
Same Side
Fig. 4b
Fig. 4c
